Equipment Advantages:
The company's patented technology - forced water cooling circulation system - is used in the production molding process, which can instantly shape and cool the corrugated pipe, effectively improving production efficiency. It is a 150% backup efficiency for other structured corrugated pipe equipment.
Technical Specifications：
Model | GS-180H | GS-300H | GS-600H | GS-1000H | GS-1200H | GS-2000H |
Min ID | 40mm | 90mm | 100mm | 100mm | 300mm | 500mm |
Max ID | 180mm | 300mm | 600mm | 800mm | 1000mm | 1500mm |
Max speed | 17.5m/min | 6.24m/min | 5.4m/min | 4.3m/min | 3.8m/min | 2.5m/min |
Max capacity | 430KG/H | 650KG/H | 1000KG/H | 1600KG/H | 1600KG/H | 1800KG/H |
Power | 270KW | 375KW | 539KW | 720KW | 890KW | 1110KW |
Center height | 1100mm | 1100mm | 1160mm | 1400mm | 1600mm | 1900mm |
Length | 26000mm | 30000mm | 32000mm | 35000mm | 37000mm | 40000mm |
Width | 2800mm | 2870mm | 3950mm | 4980mm | 5380mm | 7400mm |
Cooling water | ≧0.5㎥/min | ≧0.5㎥/min | ≧0.5㎥/min | ≧0.7㎥/min | ≧0.7㎥/min | ≧0.7㎥/min |
